堆叠两个 LTM8064 以对超级电容器 (或电池) 充电和进行主动地平衡
详情介绍
概览
产品详情
LTC3774 是一款双输出、多相 (PolyPhase®) 电流模式同步降压型开关稳压控制器，用于驱动电源模块、DRMOS 或外部栅极驱动器和功率 MOSFET。其运用了一种 LTC 专有的技术，可改善电流检测信号的信噪比，从而允许使用具非常低 DC 绕组电阻的电感器和电流检测元件，以最大限度地提升效率并降低抖动。
工具及仿真模型
LTspice
LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
To launch ready-to-run LTspice demonstration circuits for this part:
Step 1: Download and install LTspice on your computer.
Step 2: Click on the link in the section below to download a demonstration circuit.
Step 3: If LTspice does not automatically open after clicking the link below, you can instead run the simulation by right clicking on the link and selecting “Save Target As.” After saving the file to your computer, start LTspice and open the demonstration circuit by selecting ‘Open’ from the ‘File’ menu.
