概览
产品详情
LT1086 专为提供高达1.5A 的输出电流而设计。所有的内部电路均设计以在低至 1V 的输入至输出压差条件下运作，而且将压差电压作为负载电流的一个函数进行了全面的规格拟订。压差电压在多个工作点 (最高达 1.5V) 和最大输出电流条件下得到保证。当负载电流降低时，压差减小。片内修整可将基准 / 输出电压调节至 1%。另外，还可对电流限值进行调整，从而最大限度地减小过载情况下稳压器和电源电路上承受的应力。
工具及仿真模型
LTspice
LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
To launch ready-to-run LTspice demonstration circuits for this part:
Step 1: Download and install LTspice on your computer.
Step 2: Click on the link in the section below to download a demonstration circuit.
Step 3: If LTspice does not automatically open after clicking the link below, you can instead run the simulation by right clicking on the link and selecting “Save Target As.” After saving the file to your computer, start LTspice and open the demonstration circuit by selecting ‘Open’ from the ‘File’ menu.
